The SIG60 power line transceiver is capable to transfer any number of UART protocol bytes over the DC power lines at bit rates up to 115.2 Kbit/s. The IC operates both as a master or as a slave in a network of multiple SIG60 and SIG61 devices.

Description

The SIG60 IC device communicates over the DC power line using UART protocol bytes at bit rates up to 115.2 Kbit/s.

DEVICE INTERFACE

The device simply interfaces with any UART / LIN port of any microcontroller (ECU). The power-line is used for both power and data communication, thus eliminating the need for special wires for carrying control or data.

SIGNALING TECHNOLOGY

The SIG60 uses a unique multiplex digital signaling technology that overcomes the power line noisy environment. The small footprint integrates most of the analog components needed for its operation. A capacitor interfaces the SIG60 signals to the power line.

SLEEP-MODE

The device has a sleep mode for power saving, with unique power line sensing, for wake-up message detection initiated by other devices.

BIT RATES

The bit rates are selectable between 9.6 Kbit/s to 115.2 Kbit/s.

LIN-NETWORK

The SIG60 device can interface directly to a LIN host, hence eliminating the LIN transceiver. With bit rates up to 115.2 Kbit/s there is an increase of the LIN bus bit rate of up to 5 times faster compared to a traditional LIN network possible.

Operation

The SIG60 is byte oriented IC device.

Each byte that is entered to the device is modulated by a unique signaling modem and conducted via capacitor over the power line.

At the receive side, the byte is decoded and output to the external host after a fixed delay of 3.5 bits. any number of bytes can be transferred. It allows the user to define its own message protocol.

Typical Schematic

FEATURES

  • Robust UART / LIN communication over the power lines.
  • Seven delectable operating frequencies.
  • UART bit rates between 9.6 Kbit/s to 115.2 Kbit/s.
  • Can be 5 times faster than LIN network
  • Operates as Master or Slave in multiplex network.
  • Multiple networks may operate over the same power line.
  • Eliminates the UART / LIN bus wires and transceiver.
  • Sleep Mode for low power consumption
  • Small size 28 pin QFN package.

APPLICATIONS

  • Consumer electronics internal network.
  • Avionics sensors - actuators bus.
  • Transmit UART or LIN over the power line.
  • Vehicle body control - doors, seats, mirrors, A/C, lights etc.
  • Electrical vehicle Battery Management System [BMS]

PRICING

  • 1 - 49                       $7.45
  • 50 - 99                     $5.90
  • 100 - 999                 $4.85
  • 1000 - 2999             $3.96
  • 3000+ Contact Us

Pricing

  • 1 - 49                       €6.90
  • 50 - 99                     €5.46
  • 100 - 999                 €4.46
  • 1000 - 2999             €3.67
  • 3000+ Contact Us

Payment

  • Money transfer to Yamar's bank account
  • Credit Card (Visa/MC/AMX) + 2.7%
  • CONTACT US FOR QUOTATION
